Scan Pattern
Area Image (1040 x 720 pixel array)
Motion Tolerance
70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Barcode Types
Reads standard 1D, PDF, 2D, and DotCode symbologies
Host System Interfaces
1470g: USB, Keyboard Wedge, RS-232, RS485 support for IBM 46xx (RS485)
1472g: USB, Keyboard Wedge, RS-232, RS485 support for IBM 46xx (RS485)
WIRELESS (1472g only)
Radio/Range
2.4 GHz to 2.5 GHz (ISM Band)
Adaptive Frequency Hopping Bluetooth v4.2
30 m (98 ft) line of sight with Honeywell charger/communication base
Power Options
Battery: 2400 mAh Li-ion minimum
Number of Scans: Up to 50,000 scans per charge
Expected Duration of Operation: 14 hours
Expected Charge Time: 4.5 hours
