Print Specification
Resolution 203dpi
Max speed 8”/second
Max Print Width 4.25”
Print Method : Thermal Transfers /Direct Thermal
Monitor : 4 Intuitive Icon Indicator, 1 status Indicator
Memory: SDRAM 64MB Flash 128 MB
Interface: RS-232, USB 2.0, Internal Ethernet, 10/100 Mbps, USB host, for scanner or PC keyboard
Weight 9 kg (19.84 lbs)
Dimension: 248 mm (W) x 274 mm (H) x 436 mm (D) 9.76″ (W) x 10.79″ (H) x 17.17″ (D)
Sensors
• Gap transmissive sensor (position adjustable)
• Black mark reflective sensor (position adjustable)
• Ribbon encoder sensor
• Ribbon end sensor
• Head open sensor
Limited warranty
• Printer: 2 years
• Print head: 25 km (1 million inches) or 12 months which comes first
• Platen: 50 km (2 million inches) or 12 months which comes first
